ZCAM-SWS Wash System for Hazardous Areas

Call for Price
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
SKU
42326221

The ZCAM-SWS wash system is intended for use as a viewing window wash facility for CCTV cameras located in areas. The system can be used at head heights up to 10 metres.

The ZCAM-SWS wash system is intended for use as aviewing window wash facility for CCTV cameras located inareas. The system can be used at head heights up to 10metres. This enables the washer system to be located atlow level for ease of maintenance, filling and periodicrecharging.

ZCAM-SWS Wash System for Hazardous Areas

ZIZCAM moves forward the Oil & Gas Petrochemical CCTV market with a new and exciting product range. The ZCAM-SWS wash system is intended for use as a viewing window wash facility for CCTV cameras located in areas. The system can be used at head heights up to 10 metres. This enables the washer system to be located at low level for ease of maintenance, filling and periodic recharging. Utilising a 5, 10 or 25 litre fluid tank, with integral pump
the SWS provides for remotely operated window washing via client supplied camera telemetry equipment or ZIZCAM products. The switching supply voltage is connected at the integral terminal box within the JB via a suitable user supplied power cord.

Advantages

  • AISI 316L Stainless steel mounting frame.
  • HDPE tank.
  • Integral PSU and terminal box.
  • Options for alternative pumps.
  • Operating Voltage options to suit site requirements.


Technical specifications

Mounting frame: Constructed from AISI 316L Stainless Steel, electro polished.
Tank:

5, 10, or 25 litre capacity.

Material:

Polyethylene, High density and molecular weight (HDPE HMW) highly
resistant to chemicals.

Hose: EPDM rubber 4 bore x 6mm outer diameter.
Input Voltage: 24 Volt AC, Option 115 & 230VAC.
Power Consumption: 50 Watts max.
Head height: Up to 10 metres.
Weights (empty):

SWS5 - 5 litre = 3Kg
SWS10 - 10 litre = 6Kg
SWS25 - 25 litre = 10Kg



Downloads

Datasheet.pdf
