ZAB1-M2 MULTI- COLOUR FLASHING BEACON - Zone 1
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
The Ziztel ZAB1-M2 is a rugged explosion proof electronic flashing beacon which employs xenon light sources to selectively produce brilliant pulses of visible coloured light.
ZAB1-M2 MULTI- COLOUR FLASHING BEACON - Zone 1
The Ziztel ZAB1-M2 is a rugged explosion proof electronic flashing beacon which employs xenon light sources to selectively produce brilliant pulses of visible coloured light. The unit is specified for safety applications where acoustic alarms are ineffective due to excessive ambient noise and provides effective high performance visual warning annunciation. ZAB1 – M2 can be specified for use on safety critical applications as part of a PAGA Public Address and Alarm System. ZAB1-M2 is designed for reliable service on both land based and marine / offshore installations. The ZAB1-M2 beacon can be equipped with up to two different colour sources within the single housing realising major cost savings over conventional discrete multiple beacon arrays. IMO SOLAS / PFEER colour set is available i.e. Red – Yellow. Colour is assigned by specially designed Fresnel optical lens which provides highly efficient light dispersion. The unit is capable of initiating colour selection by a two-pair control cable which also includes mains power supply or ZAB-M2-A can be specified allowing energisation with control over a single pair of field cable conductors. The maximum number of devices on a single circuit is dependent on the cross-sectional area of the field cable conductors and maximum volt drop tolerance, we advise no more than forty units on a single circuit in any case to improve security. The unit utilises a totally corrosion proof stainless steel construction which minimises routine service and ensures low through life maintenance cycles.
ADVANTAGES
- Totally corrosion proof all stainless-steel construction – long through life, minimal maintenance.
- Optional colour selection over 1 x pair cable – major cost saving over conventional multi core-based systems.
- No moving parts - microprocessor controlled.
- Multiple light sources – Duplicated xenon discharge tube sets for each colour – choice of flash energy - 10, 15, 21 Joules.
- Zone 1 ATEX and IECEx certified - safe for use in hazardous areas.
TECHNICAL SPECIFICATIONS
| Light Source: | High intensity Xenon tubes |
| Security: |
Twin tubes for each colour – total four xenon discharge tubes |
| Supply Voltage: |
110 /120- 220 /240 VAC 50 / 60 Hz / 270 VAC 50 / 60 Hz To order - 24 VDC to 48 VDC |
| Tolerance: | +10% / -15% |
| Consumption: | 30 Watts / VA (60 Watts / VA peak) |
| Connectivity: |
4 x field conductors Live / Live / Common Neutral / Earth |
| Flash rate: | 1 pulse per second |
| Duty cycle: |
Continuous |
| Flash energy: |
21 Joules / colour set = suffix 21 |
| Alarm tone sub system option: |
One alarm tone type per colour |
| Alarm output: |
100 Volt line |
| Maximum load: |
25 Watts |
| Temperature Range: |
-60 ̊C - +70 ̊C |
| IP Rating: |
IP66 / 68 |
| Weight: | 4.5Kg Ex d, 6Kg Ex de |
| Dimensions Exd variant: | 170mm wide x 337mm high |
| Dimensions Exe variant: | 170mm wide x 405mm high |
| Gland entry: |
2 x 20 mm isometric cable gland entries |
| Mounting attitude: | Vertical well glass up, vertical well glass down or horizontal |
| Enclosure material: | Corrosion proof 316 l stainless steel |
| Enclosure colour: | Natural |
|
Colour selection - maximum 2 |
Violet, Red, Yellow, Green, Blue, White, Amber, split White / Green, |
|
Colour definition: |
UV Ultraviolet light resistant Fresnel optic lens – no painted well glasses |
|
Maximum cable termination |
Exd variant 2.5 mm CSA / conductor |
| Location: | Hazardous area Zone 1 IIC T4 |
| Certification: | IECEx and ATEX certified |
DOWNLOADS
Datasheet.pdf
