EXPLOSION-PROOF SPRING LOAD THERMOCOUPLE
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
MEAS
The 1023 Series explosion-proof quick release spring loaded thermocouple sensor assembly with transmitter is designed for use in various hazardous locations such as electric motors and generators. The tip sensitive, spring-loaded temperature sensor assembly is approved for use in explosion-proof and flameproof applications.
Thermocouple Sensor Type : Thermocouple
Thermocouple Type : E, J, K, T
Model Number : 1023
Overview
Explosion-proof and Flameproof Ratings
National and Canadian Electrical Code:
Class I, Division 1, Groups B, C, and D
Class II/III, Division 1, Groups E, F, and G T5 (Ta=80°C), T6 (Ta=65°C)
National Electrical Code (Article 505):
Class I, Zone 1, AEx d IIC T5 (Ta=80°C), T6 (Ta=65°C)
Canadian Electrical Code (IEC 60079):
Class I, Zone 1, Ex d IIC T5 (Ta=80°C), T6 (Ta=65°C)
ATEX:
II 2 G Ex d IIC T5 (Ta= -50°C to 80°C), T6 (Ta= -50°C to 65°C) Gb
(see datasheet for full specification)
Benefits
Variety of Configurations
Single and Dual Junctions
Stainless Steel Case with Alloy Tip
Sheath Styles: Stainless Steel with Copper or Aluminum Tip
Junction Types, Single and Dual: J, K, T, E
Grounded or Ungrounded
Sheath Diameters: .188”, .215”, .236” (6.0 mm), .250” Transmitter
U.S. or European threads available
Applications
Motors
Generators
FEATURES
| Product Type Features | Thermocouple Sensor Type Thermocouple Thermocouple Type E, J, K, T Model Number 1023 |
| Reference Number | TE Internal Number CAT-TCS0032 |
