DS-2DB4236I-CWX(T5/316L) Bullet Explosion-proof Network Camera

          Camera

• Image Sensor1/1.8" progressive scan CMOS
• Max. Resolution1920 × 1080
• Min. Illuminationcolor: 0.0005 Lux @ (F1.2，AGC ON) B/W: 0.0001 Lux @ (F1.2, AGC ON) ,0 Lux with IR
• Shutter Speed1/1 s to 1/30000 s
• Day & NightICR
• Zoom36 × optical, 12 × digital
• Slow Shutteryes

          Lens

• Focal Length6.0 to 216 mm, 36 × optical
• FOV

  Horizontal field of view: 59° to 1.98° (wide-tele)

  Vertical field of view: 34.16° to1.12° (wide-tele)

  Diagonal field of view: 67.1° to 2.3° (wide-tele)

• FocusAuto/Semi-automatic/Manual
• ApertureF1.2
• Zoom Speedapprox. 4.6 s

          Illuminator

• Supplement Light TypeIR
• Supplement Light Range200 m
• Smart Supplement Lightyes
• IR Wavelength850 nm

          PTZ

• Park Actionyes
• Scheduled TaskPreset
• Power-Off Memoryyes

          Video

• Main Stream

  50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720)

  60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)

  60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

• Third Stream

  50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)

  60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

• Video Compression

  Main Stream: H.265+/H.265/H.264+/H.264

  Sub-stream: H.265/H.264/MJPEG

  Third Stream: H.265/H.264/MJPEG

• Video Bit Rate32 Kbps to 16384 Kbps
• H.264 TypeBaseline Profile/Main Profile/High Profile
• H.265 TypeMain Profile
• Scalable Video Coding (SVC)Support
• Region Of Interest (ROI)8 fixed regions for each stream

          Audio

• Audio CompressionG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2,PCM
• Audio Bit Rate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)
• Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
• Environment Noise Filteringyes

        Network

• ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
• Simultaneous Live ViewUp to 20 channels
• APIOpen Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
• Smooth Streamingyes
• User/HostUp to 32 users, 3 user levels: administrator, operator, and user
• SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address)
• Network StorageNAS (NFS, SMB/CIFS), auto network replenishment (ANR)
• ClientiVMS-4200, HikCentral Pro, Hik-Connect
• Web BrowserIE11, Chrome 57+, Firefox 52+, Safari 11+


• Image Parameters SwitchYes
• Image SettingsSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
• Day/Night Switchauto
• Wide Dynamic Range (WDR)120 dB WDR
• SNR≥52dB
• DefogOptical defog
• Image EnhancementHLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus
• Privacy Mask24 programmable polygon privacy masks, mask color or mosaic configurable

          Interface

• Ethernet Interface1 RJ45 10 M/100 M Ethernet
• On-Board Storagesupport microSD/microSDHC/microSDXC cards, up to 256 GB
• Audio1-ch audio input and 1-ch audio output
• Alarm1-ch alarm input and 1-ch alarm output
• RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)

        Event

• Basic EventMotion detection, video tampering alarm, exception, alarm input and output
• Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
• Alarm LinkageUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording

• Deep Learning Function
• Face Capture

  1. Detects up to 10 faces simultaneously

  2. Uploads face with background and closed-up face pictures

  3. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face

        General

• Power

  100 VAC to 240 VAC & PoE+ (IEEE802.3at class4)

  Max. 25 W

• Dimension513.2 × 169 × 308 mm (20.2"× 6.65" × 12.13")
• 19.8 kg (43.66 lb.)
• MaterialSUS316L with anti-corrosion surface spray treatment
• Operating Condition-40°C to 60°C (-40°F to 140°F)，Working Humidity≤ 90%
• General FunctionAnti-flicker, heartbeat, mirror, flash log, password reset via e-mail, pixel counter, password protection, one-key reset, three streams
• Wiperyes

          Approval

• EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
• SafetyUL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252 (Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
• EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
• ProtectionIP68, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
• Explosion-Proof ProtectionEx-mark: ATEX: Ex II 2GD Ex db IIC T6 Gb /Ex tb IIIC T80℃ Db; IECEx: Ex db IIC T6 Gb /Ex tb IIIC T80℃ Db
