Interface for 1 x IS2000 ZE1-1 Zone 0 1 and 2 areas Atex and IECEx certified
€981.21
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
SKU
650371
SAP Item ID
651276
Provides an approved and easy method of connecting 1 x IS2000 PIR sensor to the outside world. Contains the correct zenner barrier to ensure no dangerous voltage or current enters the hazardous area.
Product overview
- Approved and easy method of connecting 1 x IS2000 PIR sensor to the outside world
- Contains 1 zenner barrier to ensure no dangerous voltage or current enters the hazardous area.
- Normally closed voltage free relay output
- Adjustable pulse count facility and LED indication
- Supplied complete with installation instructions
- Suitable for both external and internal use
- Fully compatible with the Voltek range of products below:
- IS2000 PIR sensors
Operating Voltage | 12VDC | |
Current Consumption | 100mA (Max) | |
Output | Voltage free normally closed relay | |
Output Z (Closed) | 200 mOhms | |
Output Z (Open) | 1016 Ohms | |
Relay V Max | 24VDC, 120VAC | |
Relay I Max | 3A | |
Enclosure Size (w x h x d) | 280mm x 190mm x 130mm | |
Weight | 1.5KG approx | |
Enclosure Material | Polycarbonate | |
Zener Barrier Description | ||
Barrier | DC Double | |
V Max | 15VDC | |
I Max | 150mA | |
Impedence | 100 Ohms | |
Pack Contents | Interface Unit and installation instructions |
