Chainway C66 scanner

Call for Price
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
SKU
42326435

Chainway C66 is a newly-developed rugged handheld computer with strong extensibility. Built with Android 9.0 OS and Qualcomm Octa-Core processor, it features 5.5-inch large display, powerful removable battery, supports quick charge and trigger handle. And it offers optional barcode scanning, RFID, NFC, etc. This mobile computer supports R6 UHF sled for good extensibility that can meet the needs in logistics, warehousing, manufacturing, retail, asset tracking, power patrol inspection, etc.

*Not Atex!

Chainway C66 scanner with imager (Non atex!)

The Chainway C66 is a newly-developed rugged handheld computer with strong extensibility. Built with Android 9.0 OS and Qualcomm Octa-Core processor, it features 5.5-inch large display, powerful removable battery, supports quick charge and trigger handle. And it offers optional barcode scanning, RFID, NFC, etc. This mobile computer supports R6 UHF sled for good extensibility that can meet the needs in logistics, warehousing, manufacturing, retail, asset tracking, power patrol inspection, etc.

Specifications

Phsyical Characteristics
Dimensions 160.0 x 76.0 x 15.5 mm / 6.3 x 2.99 x 0.61 in.
Weight 287 g / 10.12 oz. (device with battery)
Display 5.5-inch high definition full display (18:9) , IPS LTPS 1440 x 720
Battery

4420mAh(typ) / 4300mAh(min) removable main battery, 5200 mAh optional pistol battery, support QC 3.0 and RTC
Standby: up to 490 hours (only main battery ; WiFi: up to 470h; 4G: up to 440h)
Continuous use: over 12 hours (depending on user environment)
Charging time: 2.5 hours (charge device by standard adaptor and USB cable)

Touch Panel Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported
Speaker Support
Vibrator Support
Microphone USB Type-C, USB 3.0, OTG, extended thimble
Interfaces up to 256GB
Card slot

1 slot for SIM card, 1 slot for SIM or TF card

Keypad 1 power key, 2 scan keys, 2 volume keys, 1 PTT key
Sensors Gravity sensor, proximity sensor, light sensor, accelerometer sensor, vibration motor
Indicator LED Power, charging, status indicator

User Environment

Operating Temp. -20 ℃~+50 ℃
Storage Temp. -40 ℃~+70 ℃
Humidity 5% RH - 95% RH non condensing
Drop Specification

Multiple 1.8 m / 5.91 ft. drops (at least 20 times) to the concrete across the operating temperature range;
Multiple 2.4 m / 7.87 ft. drops (at least 20 times) to the concrete after installed rubber bumper

Tumble Specification 1000 x 0.5 m / 1.64 ft. falls at room temperature
Sealing IP65 per IEC sealing specifications
ESD ±15 KV air discharge, ±8 KV conductive discharge
Developing Environment
Operating System Android 9.0; GMS, 90-day security updates, Android Enterprise, Zero-Touch, FOTA, Soti MobiControl, SafeUEM supported
SDK Chainway Software Development Kit
Language Java
Tool Eclipse / Android Studio
Performance
CPU Qualcomm 1.8 GHz Octa-core
RAM+ROM

3 GB + 32 GB
4 GB + 64 GB (optional)

Expansion Supports up to 128 GB Micro SD card
UHF1
Engine CM2000-1 module based on Impinj Indy R2000
Frequency 865-868 MHz / 920-925 MHz / 902-928 MHz
Protocol EPC C1 GEN2 / ISO18000-6C
Antenna Circular Polarized Antenna (4dBi)
Power

1W (30dBm, +5 dBm to +30 dBm adjustable)
2W Optional (33dBm, for Latin America, etc.)

R/W Range Up to 15 m (open outdoors, Impinj MR6 tag)
Fastest Read Rate 900+ tags/sec
Communication Mode Pin Connector
Note

*Ranges and rates depend on tags and environment
This function is optional

UHF2
Engine CM2000-1 module based on Impinj Indy R2000
Frequency 865-868 MHz / 920-925 MHz / 902-928 MHz
Protocol EPC C1 GEN2 / ISO18000-6C
Antenna Circular Polarized Antenna (3 dBi)
Power

1W (30 dBm, support +5~+30 dBm adjustable)
2W Optional (33 dBm, for Latin America, etc.)

R/W Range Up to 10 m (open outdoors, Impinj MR6 tag)
Fasted Read Rate 900+ tags/sec
Communication Mode Pin Connector / Bluetooth
Note

*Ranges and rates depend on tags and environment
This function is optional

Communication
WLAN

Support 802.11 a/b/g/n/ac/d/e/h/i/k/r/v,2.4G/5G dual-band, IPV4, IPV6, 5G PA;
Fast roaming: PMKID caching, 802.11r, OKC;
Operating Channels: 2.4G(channel 1~13), 5G(channel36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132, 136,140,144,149,153,157,161,165),Depends on local regulations;
Security and Encryption: WEP,WPA/WPA2-PSK(TKIP and AES),WAPI- PSK—EAP-TTLS,EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS,PEAP-GTC,etc.

WWAN (Europe, Asia)

2G: 850/900/1800/1900 MHz
3G: CDMA EVDO: BC0
WCDMA: 850/900/1900/2100MHz
TD-SCDMA: A/F(B34/B39)
4G: B1, B3, B5, B7, B8, B20, B38, B39, B40, B41

WWAN(America)

2G: 850/900/1800/1900 MHz
3G: 850/900/1900/2100 MHz
4G: B2, B4, B5, B7, B12, B17, B38

Vo-LTE Support Vo-LTE HD video voice call
Bluetooth Bluetooth 4.2/4.1+HS/4.0/3.0+HS/2.1+EDR
GNSS GPS/AGPS, GLONASS, BeiDou,Galileo,internal antenna
Note *C66 models being manufactured for Turkish Market, do not include Voice Call (Phone Call) function. WAN module included on those models only support DATA transfer.
Barcode Scanning
2D Scanner Zebra: SE4710 / SE2100; Honeywell: N6603; E3200; IA166S
1D Symbologies UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
2D Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc.
Note *This function is optional
Camera
Camera Rear 13 MP Autofocus with flash
NFC
Frequency 13.56 MHz
Protocol ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
Chips M1 card (S50, S70), CPU card, NFC tags, etc.
Range 2-4 cm
Optional Accessories
Accessories

Separate handle with one button;
Handle + battery (handle battery 5200mAh, one button) ;
UHF back clip + handle (5200mAh, one button) ;
Wrist Strap; Rubber Bumper; Charging Cradle

Note *See details in Accessory Guide
