E2xL15F PA Loudspeaker - Zone 2/22 - 15W - 70/100 V
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
The hazardous area E2xL15F PA loudspeaker is UL/cULs approved for Class I Div 2 and Class II Div 2 as well as IECEx and ATEX certified for Zone 2 and 22 applications.
The E2xL15F is available with either a 70V or 100V line transformer or as a low impedance loudspeaker.
The E2x range features enclosures manufactured from lightweight, corrosion proof PPS and high impact, fire retardant ABS re-entrant flare horns; both of which are suitable for the harshest of environments.
E2xL15F PA Loudspeaker - Zone 2/22 - 15W - 70/100 V
The hazardous area E2xL15F PA loudspeaker is UL/cULs approved for Class I Div 2 and Class II Div 2 as well as IECEx and ATEX certified for Zone 2 and 22 applications.
The E2xL15F is available with either a 70V or 100V line transformer or as a low impedance loudspeaker.
The E2x range features enclosures manufactured from lightweight, corrosion proof PPS and high impact, fire retardant ABS re-entrant flare horns; both of which are suitable for the harshest of environments.
FEATURES
- Very large termination area.
- Ratchet adjustable stainless steel ‘U’ bracket.
- Transformer type fitted with thermal fuse
- Complies with BS5839 part 8
SPECIFICATIONS
| SPL: | 108dB +/-3dB @ 1w @ 1m (Pink noise) 118dB +/-3dB @ 15w @ 1m (Rated) |
| Rated power: | 15 Watts RMS |
| 70v line tappings: | 15w / 7.5w / 3w / 1w -(z=336.67 Ohms / 653.33 Ohms / 1.6k Ohms / 4.9k Ohms) |
| 100v line tappings: | 15w / 7.5w / 3w / 1w -(z=666.87 Ohms / 1.34k Ohms / 3.34k Ohms / 10k Ohms) |
| Low impedence: | 8 Ohm (I/P: 10.95V) -or 16 Ohm (I/P: 15.49V) |
| Dispersion: | 120° @ 1kHz & 32° @ 4kHz |
| Frequency range: | 400Hz to 8000 Hz |
| DC Line monitoring: | 2.2µF Capacitor -(Transformer version) |
| Ingress protection: | IP rating per EN60079-0:IP64 IP rating per EN60529:IP66 Type rating per UL50E/NEMA250:4/4X/13 |
| Enclosure material: | UL94V0 PPS & ABS |
| Cable entries: | Dual M20x1.5 or 1/2"NPT |
| Terminals: | 0.5 – 2.5mm² (20-14 AWG) |
| Operating temp: | -20 to +55°C [-4° to +131°F] |
| Storage temp: | -40 to +70°C [-40° to +158°F] |
| Relative humidity: | 90% at 20°C [68°F] |
| Weight: | Low impedance: 2.5kg/5.5Ibs -Transformer: 3.00kg/6.6Ibs |
APPROVALS
- ATEX certificate: DEMKO 06 ATEX 0421554X
- IECEx certficate: IECEx ULD 14.0012X
- UL/cUL File ref: E230764
- CSFM listing: 7136-2279:0505
CODING
- IECEx / ATEX:
II 3G Ex nA IIC T4 Gc Ta -20°C to +55°C
II 3D Ex tc IIIC T85°C Dc Ta -20°C to +55°C - NEC Class / Zone ratings US:
Class I Zone 2 AEx nA IIC T4 Gc Ta -20°C to +55°C
Zone 22 AEx tc IIIC T85°C Dc Ta -20°C to +55°C
DOWNLOADS
