The Ziztel ZAB1-M series is a rugged explosion proof electronic flashing beacon which employs xenon light sources to selectively produce brilliant pulses of visible coloured light.

ZAB1-M MULTI- COLOUR FLASHING BEACON - Zone 1

The Ziztel ZAB1-M series is a rugged explosion proof electronic flashing beacon which employs xenon light sources to selectively produce brilliant pulses of visible coloured light. The unit is specified for safety applications where acoustic alarms are ineffective due to excessive ambient noise and provides effective high performance visual warning annunciation. ZAB1 – M can be specified for use on safety critical applications as part of a PAGA Public Address and Alarm System. ZAB1-M is designed for reliable service on both land based and marine/offshore installations. The ZAB1-M beacon can be equipped with up to four different colour sources within the single housing realising major cost savings over conventional discrete multiple beacon arrays. IMO SOLAS colour set is available i.e. Red, Yellow, Amber, White or Green (note; it is possible to segment two colours e.g. Green/White if required). Colour is assigned by specially designed Fresnel optical lens which provides highly efficient light dispersion. The unit is capable of initiating colour selection by a multipair control cable which also includes mains power supply or ZAB-M-D can be specified allowing energisation and control over a single pair of field cable conductors, called ‘Data Controlled’.

ADVANTAGES

  • Totally corrosion proof all stainless steel construction – long through life, minimal maintenance.
  • Optional data controlled colour selection over 1 x pair cable – major cost saving over conventional multi-core based systems.
  • No moving parts - microprocessor controlled.
  • Multiple light sources – Duplicated xenon discharge tube sets for each colour.
  • Zone 1 ATEX and IECEx certified - safe for use in hazardous areas.


TECHNICAL SPECIFICATIONS

Light Source: High intensity Xenon tube
Security:

Twin tubes for each colour – total eight xenon discharge tubes for four

colour option

Supply Voltage Options:

110/120VAC to 220/240VAC (50/60Hz) / 270VAC (50/60Hz)

12VDC to 24VDC

Tolerance: +10% / -15%
Consumption: 30Watts/VA (60Watts/VA peak)
Initiation: 5 x field conductors (three pair cable)
Initiation suffix ‘A’ type: 2 x field conductors (single pair cable)
Duty cycle:

Continuous

Flash energy:

21 Joules / colour set

Temperature Range:

-60 ̊C - +70 ̊C

IP Rating:

IP66

Weight: 4.5Kg Ex d, 6Kg Ex de
Dimensions Exd variant: 170mm wide x 337mm high
Dimensions Exe variant: 170mm wide x 405mm high
Gland entry:

Gland entry 2 x M20 threaded isometric cable gland entries

Mounting attitude: Vertical well glass up, vertical well glass down or horizontal
Enclosure material: Corrosion proof 316l stainless steel
Enclosure colour: Natural

Colour selection - maximum 4
colours (except IMO SOLAS
possible 5 colours):

Red, Amber, Yellow, Green, Blue, Violet, White, Clear,
Split Clear/Green

Maximum cable termination
cross sectional area:

4.00mm CSA conductor
Location: Hazardous area Zone 1 IIC T4
Certification: IECEx and ATEX certified, Bahamas certified
