Chainway C66 is a newly-developed rugged handheld computer with strong extensibility. Built with Android 9.0 OS and Qualcomm Octa-Core processor, it features 5.5-inch large display, powerful removable battery, supports quick charge and trigger handle. And it offers optional barcode scanning, RFID, NFC, etc. This mobile computer supports R6 UHF sled for good extensibility that can meet the needs in logistics, warehousing, manufacturing, retail, asset tracking, power patrol inspection, etc.
*Not Atex!
Chainway C66 scanner with imager (Non atex!)
The Chainway C66 is a newly-developed rugged handheld computer with strong extensibility. Built with Android 9.0 OS and Qualcomm Octa-Core processor, it features 5.5-inch large display, powerful removable battery, supports quick charge and trigger handle. And it offers optional barcode scanning, RFID, NFC, etc. This mobile computer supports R6 UHF sled for good extensibility that can meet the needs in logistics, warehousing, manufacturing, retail, asset tracking, power patrol inspection, etc.
Specifications
| Phsyical Characteristics | |
| Dimensions | 160.0 x 76.0 x 15.5 mm / 6.3 x 2.99 x 0.61 in. |
| Weight | 287 g / 10.12 oz. (device with battery) |
| Display | 5.5-inch high definition full display (18:9) , IPS LTPS 1440 x 720 |
| Battery |
4420mAh(typ) / 4300mAh(min) removable main battery, 5200 mAh optional pistol battery, support QC 3.0 and RTC |
| Touch Panel | Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported |
| Speaker | Support |
| Vibrator | Support |
| Microphone | USB Type-C, USB 3.0, OTG, extended thimble |
| Interfaces | up to 256GB |
| Card slot |
1 slot for SIM card, 1 slot for SIM or TF card |
| Keypad | 1 power key, 2 scan keys, 2 volume keys, 1 PTT key |
| Sensors | Gravity sensor, proximity sensor, light sensor, accelerometer sensor, vibration motor |
| Indicator LED | Power, charging, status indicator |
|
User Environment |
|
| Operating Temp. | -20 ℃~+50 ℃ |
| Storage Temp. | -40 ℃~+70 ℃ |
| Humidity | 5% RH - 95% RH non condensing |
| Drop Specification |
Multiple 1.8 m / 5.91 ft. drops (at least 20 times) to the concrete across the operating temperature range; |
| Tumble Specification | 1000 x 0.5 m / 1.64 ft. falls at room temperature |
| Sealing | IP65 per IEC sealing specifications |
| ESD | ±15 KV air discharge, ±8 KV conductive discharge |
| Developing Environment | |
| Operating System | Android 9.0; GMS, 90-day security updates, Android Enterprise, Zero-Touch, FOTA, Soti MobiControl, SafeUEM supported |
| SDK | Chainway Software Development Kit |
| Language | Java |
| Tool | Eclipse / Android Studio |
| Performance | |
| CPU | Qualcomm 1.8 GHz Octa-core |
| RAM+ROM |
3 GB + 32 GB |
| Expansion | Supports up to 128 GB Micro SD card |
| UHF1 | |
| Engine | CM2000-1 module based on Impinj Indy R2000 |
| Frequency | 865-868 MHz / 920-925 MHz / 902-928 MHz |
| Protocol | EPC C1 GEN2 / ISO18000-6C |
| Antenna | Circular Polarized Antenna (4dBi) |
| Power |
1W (30dBm, +5 dBm to +30 dBm adjustable) |
| R/W Range | Up to 15 m (open outdoors, Impinj MR6 tag) |
| Fastest Read Rate | 900+ tags/sec |
| Communication Mode | Pin Connector |
| Note |
*Ranges and rates depend on tags and environment |
| UHF2 | |
| Engine | CM2000-1 module based on Impinj Indy R2000 |
| Frequency | 865-868 MHz / 920-925 MHz / 902-928 MHz |
| Protocol | EPC C1 GEN2 / ISO18000-6C |
| Antenna | Circular Polarized Antenna (3 dBi) |
| Power |
1W (30 dBm, support +5~+30 dBm adjustable) |
| R/W Range | Up to 10 m (open outdoors, Impinj MR6 tag) |
| Fasted Read Rate | 900+ tags/sec |
| Communication Mode | Pin Connector / Bluetooth |
| Note |
*Ranges and rates depend on tags and environment |
| Communication | |
| WLAN |
Support 802.11 a/b/g/n/ac/d/e/h/i/k/r/v,2.4G/5G dual-band, IPV4, IPV6, 5G PA; |
| WWAN (Europe, Asia) |
2G: 850/900/1800/1900 MHz |
| WWAN(America) |
2G: 850/900/1800/1900 MHz |
| Vo-LTE | Support Vo-LTE HD video voice call |
| Bluetooth | Bluetooth 4.2/4.1+HS/4.0/3.0+HS/2.1+EDR |
| GNSS | GPS/AGPS, GLONASS, BeiDou,Galileo,internal antenna |
| Note | *C66 models being manufactured for Turkish Market, do not include Voice Call (Phone Call) function. WAN module included on those models only support DATA transfer. |
| Barcode Scanning | |
| 2D Scanner | Zebra: SE4710 / SE2100; Honeywell: N6603; E3200; IA166S |
| 1D Symbologies | UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc. |
| 2D Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc. |
| Note | *This function is optional |
| Camera | |
| Camera | Rear 13 MP Autofocus with flash |
| NFC | |
| Frequency | 13.56 MHz |
| Protocol | ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc. |
| Chips | M1 card (S50, S70), CPU card, NFC tags, etc. |
| Range | 2-4 cm |
| Optional Accessories | |
| Accessories |
Separate handle with one button； |
| Note | *See details in Accessory Guide |
