ZCAM5-30 DOME CAMERA - Zone 1/21

Call for Price
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
SKU
42326229

 The ZCAM5-30 CCTV pan tilt zoom dome cameras developed for use in hazardous areas in all offshore, onshore and marine environments. These cameras are constructed entirely from AISI 316L grade stainless steel for low maintenance and protection from corrosion, compact and lightweight and designed for easy installation and maintenance.

ZCAM5-30 DOME CAMERA - Zone 1/21

ZIZCAM moves forward the Oil & Gas Petrochemical CCTV market with a new and exciting product. The ZCAM5-30 CCTV pan tilt zoom dome cameras
developed for use in hazardous areas in all offshore, onshore and marine environments. These cameras are constructed entirely from AISI 316L grade stainless steel for low maintenance and protection from corrosion, compact and lightweight and designed for easy installation and maintenance.
Certified for use in ATEX/IECEx hazardous gas and dust environments, the ZCAM5-30 dome camera provides for all requirements of safety and surveillance monitoring in hazardous areas.

ADVANTAGES

  • Highly reliable positioning system
  • High definition 1920 x 1080p IP
  • 30x auto focus zoom lens
  • IP67
  • Excellent low light performance
  • ONVIF conformant
  • 0.1 to 380° per second pan speed
  • Optional Ethernet fibre optic interface
  • AISI 316L Stainless Steel


TECHNICAL SPECIFICATIONS

ATEX Hazardous Area Rating: II 2 G Ex d IIC Gb
II 2 D Ex tb IIIC Db
Construction:

Stainless Steel AISI 316L,

Supply Voltage:

18-28 VAC/VDC, (Optional factory fitted 110/220VAC PSU/transformer

Power Consumption: 40 Watts max

Cable Entries:

2x M20 gland entry
Weight: 14Kg Stainless steel
Dimensions: 204 diameter, 375mm height
Mounting: Various wall/ceiling mounts attached to enclosure to suit site requirements
Operating Temperature Rating:

-20°C to +60°C, up 90% humidity

Ingress Protection: IP67
Pan Tilt travel: Pan 360 degrees continuous rotation, Tilt 90 degrees
Speed: 0.05 degree to 360 degrees/sec max, both axes
Presets/patrols:

32 preset positions with 20 character programmable titles 16 patrols of up to 16 preset positions. 4 one minute mimic tours

Camera : Full High Definition 1080p day/night camera module
Sensor: 2.1 megapixel 1/2.8” CMOS
Scanning system: Progressive
Zoom Lens: 30x Optical, f=4.3mm to 129mm F1.6 to F5.0
Angle of view: 1080p mode: 65.1o to 2.34o
Min illumination:

Colour: 0.5 Lux @ F1.6 AGC on, ICR off
BW: 0.01 Lux @ F1.6 AGC on, ICR on

Resolution:

50Hz: 25fps 1920 x 1080p
50Hz: 25fps 1280 x 720p

OSD: Time, date and title display
ICR: Yes
WDR: Yes
DNR: Yes 3D
Video compression: H.264 dual stream
Encoder Output: 1080p and D1
Protocol:

TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP,

UPnP, SNMP, FTP, QoS, HTTPS, IPv4/IPv6

ONVIF: Profile S



DOWNLOADS

Datasheet.pdf
