ZCAM-WS-285 Pressurised Wash System for Hazardous Areas
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
The ZCAM-WS-285 pressurised wash system is intended for use as a viewing window wash facility for CCTV cameras located in hazardous areas. The system can be used at head heights up to 20 metres.
ZCAM-WS-285 Pressurised Wash System for Hazardous Areas
ZIZCAM moves forward the Oil & Gas Petrochemical CCTV market with a new and exciting product range.The ZCAM-WS-285 pressurised wash system is intended for use as a viewing window wash facility for CCTV cameras located in hazardous areas. The system can be used at head heights up to 20 metres. This enables the washer system to be located at low level for ease of maintenance, filling and periodic recharging. Utilising a manually pressurised 10 litre fluid tank, the WS-285 provides for remotely operated window washing via client supplied camera telemetry equipment or ZIZCAM products. The solenoid switching supply voltage is connected at the integral solenoid terminal box within the cabinet via a suitable user supplied power cord.
ADVANTAGES
- AISI 316L Stainless steel protective enclosure.
- Stainless steel pressurised tank.
- Manually pressurised up to 4 bar.
- Integral pressure gauge and release valve.
- ATEX Certified solenoid valve with.
- Integral Ex e terminal box.
- Options for alternative solenoid valves.
- Operating Voltage options to suit site requirements.
TECHNICAL SPECIFICATIONS
ATEX Solenoid Certification: | II 2GD Ex e m IIC T4 |
CE Approval: |
CE Compliant to ATEX 94/9/EC and EMC 2004/108/EC Directives. |
Cabinet Construction: |
Stainless Steel AISI 316L. |
Solenoid Voltage: | 24 Volt AC/DC, Option 110 & 220VAC. |
Power Consumption: | 10 Watts max. |
Head height: | Up to 20 metres @4 Bar maximum. |
Weight: | 26Kg full |
Mounting: |
Up to 6 x M10 fixings via cabinet rear plate. |
Temperature Rating: |
-30°C to +60°C. |
Ingress Protection: |
IP65 solenoid terminal box only. |
