ZCAM4-5 HD IP PTZ CAMERA - Zone 1/21
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
The ZCAM4-5 uses technology new to the CCTV industry, providing outstanding and ultra-reliable performance. Each axis is driven directly without intermediate belts or gears by our unique brushless DC digital servo drives to give a previously unattainable level of positional accuracy, repeatability, zero backlash, smoothness and silent operation.
ZCAM4-5 HD IP PTZ CAMERA - Zone 1/21
ZIZCAM moves forward the Oil & Gas Petrochemical CCTV market with a new and exciting product. The ZCAM4-5 uses technology new to the CCTV industry, providing outstanding and ultra-reliable performance. Each axis is driven directly without intermediate belts or gears by our unique brushless DC digital servo drives to give a previously unattainable level of positional accuracy, repeatability, zero backlash, smoothness and silent operation. This results in military performance at commercial cost, with very long life and maintenance free, leading to low cost of ownership. The ZCAM4-5 motors have positional intelligence, and will maintain or recover to its correct position immediately in heavy winds or being knocked out of position. The ZCAM4-5 is constructed entirely from AISI 316L stainless steel for low maintenance and protection from corrosion, small in appearance, lightweight and designed for easy installation and maintenance. Certified for use in ATEX/IECEx hazardous gas and dust environments, the ZCAM4-5 range provides for all requirements
of safety and surveillance monitoring for hazardous areas.
*Let us know the following to make an quotation:
- Voltage Required
- Video Management System Used
- Analytics required
- I/P or O/P required
- Conduit cable tail length
- Aluminium or Stainless Steel
- Preferred Camera Module Brand (Axis, Bosch, Sony, Samsung)
- Are Wash Tanks Required
- Junction Box Required
ADVANTAGES
- High Definition (HD 1080p) onboard camera
- Continuous 360 degree rotation
- Direct drive, Zero backlash Brushless DC motors for longevity
- Outstanding accuracy and dynamic range
- AISI 316L Stainless Steel
- ONVIF compliant
- Direct Fibre output or Ethernet
TECHNICAL SPECIFICATIONS
| ATEX Hazardous Area Rating: | II 2 G Ex db, eb, op-pr, IIC T6-T4, Gb,Tamb -60°C to +70°C II 2 D Ex tb IIIC T135°C Db |
| IECEx Hazardous Area Rating: |
Ex db, eb, op-pr, IIC T6-T4, Gb, Tamb -60°C to +70°C |
| CE Approval: |
CE Compliant to ATEX 2014/34/EC and EMC 2014/30/EU Directives |
| Construction: | Stainless Steel AISI 316L |
|
Supply Voltage: |
48VDC 2.0A max (Optional factory fitted 85-264VAC Mains PSU in base) |
| Power Consumption: | 72 Watts max |
| Cable Entries: | 2 x M20/M25 Ex d barrier gland entry at base, Power, Ethernet CAT6 or Fibre Optic field cables |
| Weight: | 22Kg |
| Mounting: |
4 x M10 fixings on 164mm PCD |
| Certified Temperature Rating: | -60°C to +70°C |
| Operating Temperature: | -20°C to +60°C standard (-40°C & -60°C option on request) |
| Ingress Protection: | IP66, IP67 & IP68 |
| Pan Angle: | 360° continuous rotation |
| Tilt Angle: | +90°/-90° max from horizontal (360° continuous rotation option) |
| Preset positions: | 200 Fitted as standard, optical encoder. |
| Positioning accuracy: | +/- 0.02° |
| Speed: | Variable 0.05 to 200°/sec Pan and Tilt (nominal) zero backlash. Proportional Pan/Tilt control, continually matches pan and tilt speeds to zoom position |
| Pan Tilt Motor Drive: | 48VDC variable speed, brushless DC motors |
| Lens Control: | Via integral serial interface Pelco protocol |
| Communication: | Ethernet to internal encoder RS422/RS485 Pan Tilt interface and washer contro |
| Auxiliary relay Protocols: | Pelco P and D as standard, or to customer specification |
| Auxiliary Relays: | 2 x 24VDC relays for wash wipe |
| Imager: | 1/2.8" CMOS Progressive scan |
| Effective Pixels: | 2.1 Megapixels |
| Resolution: | 1920 x 1080p @ 25fps |
| Optical Zoom: | 30x |
| Digital Zoom: | OFF/ON (max. 12x) |
| Focal Length: | 4.3mm to 129mm, F1.6(Wide) / F5.0(Tele) |
| Horizontal angle of view: | 65.1° to 2.34° (Wide-Tele) |
| Focus: | Auto/Manual |
| Day & Night: | Auto/Manual (ICR) Colour / B/W |
| Iris: | Auto |
| Wide Dynamic Range | Yes |
| Digital Noise Reduction: | 3D |
| Shutter speed: | 1/1 sec~ 1/10,000 sec |
| Backlight compensation | On/Off |
| White Balance: | Automatic with manual override |
| Minimum illumination: | Colour: 0.5 Lux, B/W: 0.01 Lux ICR on |
| Ethernet connection: | RJ-45 (10/100BASE-T) or Direct Fibre output via media converter or SFP in base |
| Video Compression: | H.264 Main, MJPEG |
| Encoder output: | 1080p and D1 resolutions, 25fps |
| Video bitrate: | 32kbps-12Mbps |
| Streaming: | Dual streaming H.264 |
| Protocol: | TCP/IP, HTTP, DCHP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, SNMP, FTP, QoS, HTTPS, IPv6 |
| Security: | Login authentication, Password protected |
| Operation: | Via Web Page, ONVIF, SDK available |
DOWNLOADS
Datasheet.pdf
